I/O ports and slotsI/O ports and slots
8 RJ-45 autosensing 10/100/1000 Class 4 PoE ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX,
IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only 2 SFP 1GbE ports"
Physical Characteristics
Dimensions 10(w) x 10(d) x 1.73(h) in (25.4 x 25.4 x 4.39 cm) (1U height)
Weight7.21 lb (1.16 kg)
Processor and memory
ARM Cortex-A9 @ 800 MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5 MB
Performance
100 Mb Latency< 5.2 uSec
packet size64B
1000 Mb Latency<3.0 uSec
packet size64B
10000 Mb Latencyn/a
packet sizen/a
Throughput (Mpps)14.88 Mpps
packet size64B
switching capacity20 Gbps
Routing Table size (# of static entries)32 static entries
MAC Address table size (# of entries)8,000 entries
Reliability MTBF (years)95
